3.5 Inch High Brightness TFT 320*240 Color LCD Display

SCT035001-V11 is a 3.5 inch High brightness TFT LCD Display with 320*240, HX8238 IC, RGB, 54 PIN, 12 o’clock.

  • Type: TFT
  • Mode: TN
  • Product No: SCT035001-V11
  • Size: 3.5''
  • Resolution: 320*240
  • Outline Dimension: 76.90*63.90*3.27
  • Active Area: 70.08*52.56
  • Interface: 24bit RGB
  • IC: HX8238D
  • Brightness: 1000cd/m2
  • Touch Screen: No
  • View Direction: 12
  • Pin No: 54
  • Shape: Rectangle
Inquiry Now

Introduction:

sunlight readable LCD

General Specification





ItemNominal DimensionUnit
Dot Matrix320 x RGB x 240Dots
Module Size ( W×H×T )76.90*63.90*4.40mm.
Active Area ( W×H )70.08*52.56mm.
Color depth262K(MAX)colors
Interface24bit RGB with Serial Interface
Driving ICHX8238-D
Operating temperature-20 ~70ºC
Storage temperature-30~80ºC
LCD TypeActive maritx TFT, Transmissive type
LCD ModeTN / Normal White
Backlight TypeLED x 9PCS



 Interface Definition
